Performance characteristics：
1. High processing efficiency, good surface quality, and no marking required
2. Save wood, wide processing range, automatic programming, simple operation, division of labor between man and machine, reduce the risk of work-related injuries
3.Small footprint, large processing range, high efficiency
4.Economical and practical, to solve curve processing for many users
Technical parameters：
Processing size | 1000*2500mm/1500*2500mm/2000*2500mm |
Processing thickness | ≤150mm | Processing type | Non-metallic |
Rail slider | Imported linear square rail, slider | Transmission screw | Taiwan TBI ball screw |
Transmission rack | Imported high-precision helical gear rack | Speed reducer | Precision planetary reducer |
Spindle motor | 7.5kw*2 high-speed spindle motors | Power supply | 380v/220v 50HZ |
Control system | Dedicated three-axis CNC system | Drive mode | Pure servo drive/servo motor |
Operation interface | Independent research and development to simplify the operation interface | Control appliances | Delixi, Chint, Omron |
Bed structure | Thick-walled square steel (heavy duty) | Empty line speed | 0-30m/min speed adjustable |
Processing speed | 0-10m/min | Pressing method | Pneumatic compression |
Use air pressure | 0.6-0.8Mpa | Vacuum port | Ø100
|
